DLS-LHOP20240711011
C-Laser
General Introduction:This material was developed by OHARA based on our knowledge of High Homogeneity melting and Precise Crystallization. This material is produced under tightly controlled conditions and offers outstanding thermal, mechanical and chemical properties.
Products Name: OHARA Clearceram-Z Ultra-low Expansion glass-ceramic
Alias:Ohara Clearceram-Z glass-ceramic, Ohara CCZ glass-ceramic, Ohara CCZ HS glass-ceramic, Ohara CCZ glass, Ohara CCZ HS glass, Ohara Clearceram Ultra-low expansion glass, Ohara CCZ, Ohara CCZ-HS, Ohara Clearceram CCZ,Ohara Clearceram CCZ Hs, OHARA Microcrystalline glass etc
Main Characteristics:
Extraordinary features
1) The zero expansion glass ceramics have special properties. When the temperature changes, the change of geometry and distance is almost zero.
2) Very low coefficient of thermal expansion (CTE), suitable for a wide range of temperatures
3) Excellent CTE uniformity throughout the material
4) The degree of defect is very low
5) A variety of accurate geometric shapes can be obtained by grinding process
6) When the residual roughness is less than 1 nm, the surface may be very smooth
7) Excellent chemical stability
8) All of these features enable extraordinary reproducibility for small components and for large ton telescopes used in astronomy
Thermal Expansion Properties:
| Model | Coefficient of Thermal Expansion |
| CCZ Regular | 0.0±1.0×10-7/˚C |
| CCZ HS | 0.0±0.2×10-7/˚C |
| Coefficient of Thermal Expansion of is guaranteed for the temperature range of 0~50°C. | |
Thermal Conductivity:
| ITEM | CCZ | CCZ HS |
| Thermal Conductivity (W/(m•K)) | 1.51 | 1.52 |
| Thermal Diffusion (×10-4m2/s) | 0.00762 | 0.00775 |
| Specific Heat (kJ/(kg•K)) | 0.777 | 0.773 |
Mechanical Properties:
| Item | Unit | CCZ | CCZ HS |
| Density | g/cm3 | - | - |
| Yong's Module | GPa | 90 | 90 |
| Poisson's ratio | 0.25 | 0.25 | |
| Compression strength | GPa | 1.1 | |
| Bending strength | MPa | 116 | 111 |
| Tensile strength | MPa | 55 | |
| Torsional rigidity | GPa | 36 | 36 |
| Vickers hardness | GPa | 6.8 | 7.0 |
| Knoop hardness | Kg/mm2 | 6.0 | 6.4 |
| Abrasion Aa* | - | 62 | 64 |
| Coefficient of thermal expansion | cm/cmºC | - | - |
| Softening point | ºC | - | - |
| Annealing point | ºC | - | - |
| Strain point | ºC | - | - |
| Specific heat(26ºC) | kJ/kgK | 2.55 | 2.55 |
| Thermal conductivity ratio(26ºC) | cal/cm.sec.ºC | - | - |
| Thermal conductivity ratio(100ºC) | Cal/cm.sec.ºC | - | - |
Main Applying Fields:
| Applying Fields: | High tech application Zero expansion glass ceramics have become a decisive factor in the performance and quality of many modern technology applications as following: 1).Platform and mirror for IC and LCD lithography equipment 2).Mirror substrate for segmented and large monolithic telescopes 3).Ultra light weight mirror blank 4).Technical standard for precision measurement 5).High precision mechanical parts, such as ring laser gyroscope |
| ***** |
Matching Custom Manufacturing Serivce:
Including Moulding, CNC machining, Polishing, Particle beam processing, Magnetic flux conversion processing, Grinding, Coating, Lightweighting, Custom Shaping, Counterbores, Drilling & Coring, Edge & Bevel Polishing,3D Contouring, Bevels & Chamfers, Steps & Slots, Laser Cutting & Marking, Metrology & Inspection, Precision Pitch Polishing, Double-Sided Polishing, Optical Assembly, Measuring, etc.
Matching processing equipments;
1).Single side lapping and polishing machines
2).Duble sided polishing machines
3).Ring throwing machines
4).DMG five-axis five-linkage spherical milling machine
5).DMG ultrasonic machining center
6).Super large scale gantry cnc machining center (2.0*2.0m)
7).Super large scale surface grinder (1.6m*1.6m)
8).CNC cutting machines
9).Thin plate cleaning machines
10).Ultrasonic trough cleaning machines
11).Plane interferometers
12).Two dimensional detectors
13).Ion beam polishing machines
14).Magnetorheological polishing equipments
Main Cooperation Materials Manufacturers:
CORNING, OHARA, SCHOTT, LEONI, AGC,HELLMA, NIKON,VITRON,C-LASER,ETC
Main Export Countries & Areas:
Usa, Uk, Japan, Germany, Spain, France, Swiss, Korea, Russia, Pakistan, India, Portugal, Canada, New Zealand, Australia, Saudi Arab, Turkey, Finland, Poland ,etc.
Extra value added services offered:
1). Optical workcraft & process solution design;
2). Rough processing raw materials;
3). Semi finishing raw materials;
4). Fabricate custom sizes and shapes;
5). Design and supply custom coatings;
6). Modify and resurface customer supplied materials;
7). Drill holes, notch glass and provide beveled substrates;
8). Precision polish optics with non-standard aspect ratios;
Payment Method: by T/T or Western Union.
Delivery time: 7-10 days.
